GENERAL
DIMENSIONS 12,0 x 8,4 x 3,9 m
FALL HEIGHT 2,00 m
AGE 3 - 15
ASSEMBLY 3p. - 30h.
SAFETY ZONE 132,5 m²
CERTIFICATION EN-1176
CONCRETE REQUIRED Yes
MATERIALS
- Type of wood: larch; ladder rungs in ash
- 12 cm thick round wooden poles cut outside the heart
- Roof boards with edge 22 mm thickness
- HDPE polyethylene sheet material 19 mm thick
- Floor boards 22mm thick
- Staircase with integrated rungs of 35 mm thickness
- Low stainless-steel slide with HDPE polyethylene sidewalls
- Footbridge on steel wire; boards 45 x 95 mm
- Climbing ladder with integrated rungs 40 mm
- Ropes and nets in 16 mm polypropylene rope with steel-wire reinforcement
- Galvanized metal base supports
- Plastic clamps
- Metal parts treated against rust and polyester coated
